Rechargeable Coaxial Traps With Copper Media
The VSRC series foreline trap provides a rechargeable shield within your vacuum system. These traps can protect your system from backstreaming pump oil and/or your pump from contaminates created upstream within your system.
Features
- Fully charged
- Flanged body connection for large body diameter to ease assembly and ensure consistent seals.
- 2-stage trapping system
- Stage 1: stainless steel baffle – extends the life of the media
- Stage 2: coalescing media
Specifications
- Materials:
- Body, flanges and baffle: 304L stainless steel electropolished
- Seal: Buna-N
- Trapping media: COPPER. Provides protection from pump fluid back streaming.
*Dimensions are in inches unless otherwise specified
| Part ID | Reference Number | A | B | C | Connection | 3D CAD | Drawing | Unit Price | In Stock | Qty, Add To Cart | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part ID | 7500101 | Reference Number | VSRC-200-QF16-C | A | 2 | B | 3.8 | C | 5.9 | Connection | QF16 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $330.00 | Contact | |
| Part ID | 7500111 | Reference Number | VSRC-250-QF16-C | A | 2.5 | B | 3.8 | C | 5.9 | Connection | QF16 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $358.00 | Contact | |
| Part ID | 7500131 | Reference Number | VSRC-400-QF16-C | A | 4 | B | 5 | C | 7 | Connection | QF16 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $523.00 | Contact | |
| Part ID | 7500115 | Reference Number | VSRC-250-QF25-C | A | 2.5 | B | 3.8 | C | 5.9 | Connection | QF25 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $369.00 | Contact | |
| Part ID | 7500121 | Reference Number | VSRC-300-QF25-C | A | 3 | B | 4.8 | C | 6.9 | Connection | QF25 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $435.00 | Contact | |
| Part ID | 7500135 | Reference Number | VSRC-400-QF25-C | A | 4 | B | 5 | C | 7 | Connection | QF25 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $534.00 | Contact | |
| Part ID | 7500125 | Reference Number | VSRC-300-QF40-C | A | 3 | B | 4.8 | C | 6.9 | Connection | QF40 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $473.00 | Contact | |
| Part ID | 7500139 | Reference Number | VSRC-400-QF40-C | A | 4 | B | 5 | C | 7 | Connection | QF40 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $545.00 | Contact | |
| Part ID | 7500151 | Reference Number | VSRC-600-QF40-C | A | 6 | B | 7.3 | C | 9.4 | Connection | QF40 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $655.00 | Contact | |
| Part ID | 7500143 | Reference Number | VSRC-400-QF50-C | A | 4 | B | 5 | C | 8 | Connection | QF50 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $567.00 | Contact | |
| Part ID | 7500155 | Reference Number | VSRC-600-QF50-C | A | 6 | B | 7.3 | C | 10.4 | Connection | QF50 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $688.00 | Contact | |
| Part ID | 7500159 | Reference Number | VSRC-600-LF63-C | A | 6 | B | 7.3 | C | 10.4 | Connection | LF63 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $781.00 | Contact | |
| Part ID | 7500171 | Reference Number | VSRC-800-LF63-C | A | 8 | B | 7.3 | C | 10.4 | Connection | LF63 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $1,194.00 | Contact | |
| Part ID | 7500163 | Reference Number | VSRC-600-LF80-C | A | 6 | B | 7.3 | C | 10.4 | Connection | LF80 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $842.00 | Contact | |
| Part ID | 7500175 | Reference Number | VSRC-800-LF80-C | A | 8 | B | 7.3 | C | 10.4 | Connection | LF80 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $1,216.00 | Contact | |
| Part ID | 7500179 | Reference Number | VSRC-800-LF100-C | A | 8 | B | 7.3 | C | 10.4 | Connection | LF100 FLANGE | 3D CAD | Login | Drawing | Login | Unit Price | $1,243.00 | Contact |
