CF275-000-DS-0.750

Product Features:

• Same size CF flange on both sides
• Ideal to add a spacer to your system or customize with a radial port
• Requires special CF double-sided flange bolt kit for fastening
• Use standard CF gaskets to seal
• Self-aligning
• Sexless flanges
• Interchangeable with other ConFlat style flanges

Product Features:

• Vacuum rated: UHV (approx. 1×10^-13 Torr)
• Temperature range: -200^oC up to 450^oC
• Standard materials: 304L stainless steel

Options: Contact us for price and availability

• Tapped bolt holes
• Alternative materials: 316L stainless steel, aluminum, etc.
