Rechargeable Coaxial Traps

The VSRC series foreline trap provides a rechargeable shield within your vacuum system. These traps can protect your system from backstreaming pump oil and/or your pump from contaminates created upstream within your system. The design of the rechargeable Vacu-Shield traps allows multiple trapping media to be used with the same body. The VSRC traps have a coaxial port design for installation and a simple 2-piece clamped body design for easy media recharging and trap cleaning. A rechargeable trap is recommended for applications that experience heavy gas loads or continuous use.



    • Trapping media: copper, stainless steel, activated alumina, activated charcoal
    • System protection from pump oil backstreaming
    • Pump protection from water, particulates, organic condensibles, and acids
    • 2-Stage trapping system
      • Stage 1: stainless steel baffle – extends the life of the media
      • Stage 2: adsorbent or coalescing media2-stage trapping system
    • Simple, clamped two piece body design
    • Electropolished body: Eases cleaning and reduces iron concentration on trap surfaces; increases corrosion resistance
    • ISO-QF connection (contact technical sales for other connection options)
