REPRESENTATIVE IMAGE

Attributes

Description (1) Copper Gasket
Use with Flange WF1900
3D CADLogin
DrawingLogin

All dimensions are in inches unless otherwise specified.

WF1900-GA-CO

Wire Seal Copper Gasket for WF1900-HBK

Part ID: 0606514

































Request a Quote for Price









Available on backorder





















			Standard Lead Time:

Contact









































































Wire seal gaskets are compressed between a pair of mating male and female wire seal flanges to provide a vacuum-tight seal rated for ultra-high vacuum processes at 1×10-13 Torr and temperatures up to 450°C. Use a new copper gasket each time you install a Wire Seal Flange.




Features






  • Single-use seal
    •









Specifications






  • Materials: OFE copper
    •

  • Temperature range: -200°C up to 450°C
    •

  • Pressure range: UHV (approx. 1×10-13 Torr)
    •
