REPRESENTATIVE IMAGE

Attributes

A 6
B 7.3
C 10.4
Connection LF63 FLANGE
3D CADLogin
DrawingLogin

All dimensions are in inches unless otherwise specified.

VSRC-800-LF63-A

8″ diameter Activated Alumina Trap with LF63 Flange Connection

$1,194.00

Available on backorder

Part ID: 7500173


Features

  • Trapping media: ACTIVATED ALUMINA. Provides protection from pump fluid backstreaming, light water vapor loads, and acids.
  • Flanged body connection for large body diameter to ease assembly and ensure consistent seals.
  • 2-stage trapping system
    • Stage 1: stainless steel baffle – extends the life of the media
    • Stage 2: coalescing media
  • Materials:
    • Body, flanges and baffle: 304 stainless steel electropolished
    • Seal: Buna-N
  • Fully charged
